CV Self Propelled Sprayer
+44 (0)1379 588286 | sales@landquip.co.uk
Metfield Road, Fressingfield, Suffolk, IP21 5SD, Uk Tel +44 (0)1379 588286 | Email sales@landquip.co.uk
Model/Capacity Fibreglass tanks
Tier 5 Final Turbo Diesel Engine
Wheel Motors
Wheel Base (metres)
Wheels
CV 3000/3500
170 hp
8 stud
3.16
12.4 R36 14.9 R34
CV 4000/5000/6000
228 hp
12 stud High Torque
3.60
14.9 R34
The CV is a purpose built self propelled sprayer with hydrostatic drive and selectable 2/4 wheel steering. Excellent underbelly clearance & new unrivalled in-cab comfort.
Standard CV sprayer features include:- Heavy duty high lift pantagraph and chassis Efficient clean water flushing system Efficient sump complete with drain tap Mechanical, chemical-less sight gauge Tank washing rotaflush heads 15 litre operator hand wash water tank Electro-hydraulic controls for boom folding etc. Alu-light 'gull-wing' folding booms - bi-fold 24-32 metre or tri-fold 30-44 metre Trapezium self-levelling boom Hydraulic anti-yaw protection (patented) Hydraulic boom tilt Hydraulic variable geometry Stainless steel ½” spray lines + Poziflow spray line constant recirculation Poziflow electric over air spray on/off Removable quick fit boom tube end caps Tri, quad, or quin 360o nozzle bodies + 2 sets of multi select colour coded quick fit caps 2 sets of ceramic ISO colour coded tips Boom pressure filters Multi section, in cab electric spray controls Master, pressure & 4 section valves (bi-fold boom), 6 section valves (tri-fold boom) Large suction filter Hyd driven 6 cylinder 330 l/min. piston diaphragm pump (450 l/min on 4000, 5000, 6000) Swing down 30 litre easy clean chemical bowl with can wash, rinse & agitation jets 6 metre 2” suction/fill hose Spray height up to 2.3 metres All round work and road lights and indicators M6-M16 stainless steel nuts, bolts and hoseclips throughout
CanBus Engine Management and Rate Control System The very best weight distribution 1.1m (44”) axle clearanceas standard Level Airide all round pneumatic suspension Adjustable 24” wide mudguards Electric/battery isolator - Electric wing mirrors Panoramic all round cab vision - Climate control Air seat & Buddy seat - Adjustable steering column
